Product Summary

The FS453LF is a TV encoder. The FS453LF is specifically designed for devices requiring high quality video output. The FS453LF accepts various data inputs, including RGB, and YCrCb, through a programmable digital input interface that supports 24/18/16/12/8 bit pixel data lengths. Ouput resolutions from NTSC (720X480) to 1080i can be supported with this device. The applications of the FS453LF include Cell Phones/Smart Phones, GPS/Auto/Handheld, DVB-H devices/DMB devices, Cameras/Camcorders, DVD Players, Gaming Platforms, Set-top boxes and Digital Video Recorders.

Features

FS453LF features: (1)RGB or YCrCb digital inputs; (2)NTSC, PAL, YPbPr, VGA output; (3)Four 10bit DAC; (4)Advanced 2D Flicker Filter; (5)Advanced 2D Scaling; (6)Macrovision 7.1.L1; (7)7mm x 7mm, 88 ball, FBGA; (8)14mm x 14mm, 80 pin, PQFP.

Diagrams

FS453LF block diagram
